Tiger 100% Copper Wire Gasoline Medium Seize 2.0kw to 2.5kw Generator

Overview

Basic Info.

Model NO.	TG2700, TG3700, TG2700E, TG3700E
Standard	Standard
Model	Te160(E),Te200(E)
Max Output	5.5HP 6.5HP
DC Output	12V/8.3A
Noise Level	65dB
Starting System	Recoil/Electric
Displacement	163/196
Voltage	220V
Rated Current	9.1/11.4
Frequency	50Hz
Material	Iron, Copper,Steel
Start	Hand Start
Transport Package	Seaworthy Package
Specification	525X460X460
Trademark	TIGER BRAND
Origin	China
HS Code	850220000
Production Capacity	500000pieces/Year

Product Description

Product Parameters

Generator Model	TG2700	TG3700	TG2700E	TG3700E
Frequency(Hz)	50	50	50	50
Voltage (V)	220	220	220	220
Rated Output(KW)	2	2.5	2	2.5
Max. Output(KW)	2.3	2.7	2.3	2.7
Rated Current (A)	9.1	11.4	9.1	11.4
DC Output(V/A)	12V/8.3A	12V/8.3A	12V/8.3A	12V/8.3A
Model	TE160	TE200	TE160E	TE200E
Max. Output(HP)	5.5	6.5	5.5	6.5
Displacement(cc)	163	196	163	196
Starting System	Recoil	Recoil	Recoil/Key Start	Recoil/Key Start
Engine Type	Forced air-cooled, 4 stroke, OHV	Forced air-cooled, 4 stroke, OHV	Forced air-cooled, 4 stroke, OHV	Forced air-cooled, 4 stroke, OHV
Ignition System	Non-contact transistorized ignition (T.C.I)	Non-contact transistorized ignition (T.C.I)	Non-contact transistorized ignition (T.C.I)	Non-contact transistorized ignition (T.C.I)
Fuel Tank (L)	12	12	12	12
Oil Capacity (L)	0.6	0.6	0.6	0.6
Package	TG2700	TG3700	TG2700E	TG3700E
Dimension(L x W x H)mm	525X430X460	525X430X460	525X460X460	525X460X460
G.W(Kg)	39	42	44	47
20'FCL(pcs)	275	275	260	260

ADVANTAGE:
•Low vibration, low emission, more durable, more stable, more reliable and more powerfu
•Economical and efficient, fuel saving(accurate control of ignition according to the load of intelligent speed control)
•Humanized design concept, integrated panel operation, easy to see operation, easy to switch between oil and gas, stable performance
AFTER SALES SERVICE

1. Supply you top quality products with competitive price under the same quality level, different products according to yourdifferent market demands.2. Strictly control the whole production process and guarantee punctual delivery, test each of our products one by one beforepacking to ensure the quality.3. Supply you a good pre-sale, in-sale and after-sale Service. We're not just working partners, but also Friends and Family.4. We have engine engineer,water pump engineer, generator engineer,strong technical team.5. When you come to our Factory, we will try our best to supply you all services to make you feel like at home.

FAQ

1. Are you a manufacture or trading company?We are a manufacture specilized in producing gasoline&diesel engine/generator/pump set, water pump.2. What kind of certificate can you offer?ISO, CE3. Can you accept OEM?Yes, we can accept OEM.4. What is your warranty period? Our warranty: 1 year from BL date .5. What's your delivery time?45-60 days for container order and 20 days for sample order.

Certifications

Company Profile

TIGER INDUSTRIAL GROUP was founded in 1998. As a professional manufacturer, our Products are well received in more than one hundred countries such as Middle East, Africa, Southeast Asia, Europe and South America, etc. Our company introduces high-grade science and technology development, continually improving our technology development ability. We have excellent board of management and modern equipments for testing our products in order to achieve perfection and give the best quality production to this market. With the development of comprehensive management , improved technology , we win the widely acceptance and trust of customer.

Factory Display

Packaging & Shipping
